BIB J40: Top Icons Overview

Top Icons on Main Robot Screen From Left to Right


This symbol shows whether the robot is online or not. If the robot is online and able to be accessed remotely, it will show a checkmark inside the rectangle. If it is offline, an "x" will be inside the rectangle. If the robot is offline, tech support will not be able to access the robot to help with troubleshooting or access any task data.

This symbol shows whether or not the robot is connected to WIFI. An "!" in front of this symbol means it is NOT connected. The robot needs to be connected to WIFI for remote access to work and for task logs to upload into the cloud.


This symbol shows whether or not the robot is using Data from a SIM card.

This symbol shows whether or not the robot knows its location. If it does, there will be a checkmark inside the circle. If it does not, there will be an "x" inside the circle. The robot cannot perform tasks if it does not know its location. Initialize the robot if there is an "x" in this symbol.

This symbol shows the level of dirty water inside the robot.

This symbol shows the level of clean water inside the robot.

This symbol shoes the level of battery the robot has.


This symbol is the current time.

Still need help? Click "Submit a Ticket" at the bottom of the page.
You can also call our tech support office at 724.799.8157.
